XNMU0705ANN-F57 WKP35G Solid Carbide Insert, Grade WKP35G, TiAlN - Walter 7169072

Walter

XNMU0705ANN-F57 WKP35G Solid Carbide Insert, Grade WKP35G, TiAlN - Walter 7169072

MFR# 7169072ISO/ANSI# XNMU0705ANN-F57 WKP35GCat# XNMU0705ANN-F57Series XNMU

$38.57List $49.47 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeHeptagon
GradeWKP35G
MaterialSolid Carbide
CoatingTiAlN

Description

The Walter 7169072 is a XNMU0705ANN-F57 WKP35G solid carbide indexable insert, grade WKP35G, TiAlN coated. Suited for steel, cast iron.

Specifications

Ansi codeXNMU0705ANN-F57 WKP35G
Chip breakerF57
Coating finishTiAlN
Coating processCVD
Corner radius in1/32
Cutter series compatibilityM3024
Cutting edge styleChamfered; Honed
Hole diameter0.1598
Included angle degree128.57
Inscribed circle0.5710
Inscribed circle range0.5100 to 0.6000
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeHeptagon
Insert size07
Insert size code0705
Insert styleXNMU
Iso codeXNMU0705ANN-F57 WKP35G
Length0.5710
Length range0.5000 to 0.6000
Manufacturers catalog numberXNMU0705ANN-F57
Manufacturer gradeWKP35G
Material applicationSteel; Cast Iron
Material gradeP35; K35
Maximum depth of cut0.2750
Multi use toolYes
Number of cutting edges14
Primary workpiece materialSteel; Cast Iron
RakeNegative
Rake angle16
Relief angle0.00
Single or double sided insertDouble
StandardsANSI; ISO
Thickness0.1970
Thickness range0.1850 to 0.2000
Width0.5710
