Walter
TNMU160508R-G27 WKP35G Carbide Insert, Grade WKP35G, TiAlN/TiN - Walter 8209399
MFR# 8209399ISO/ANSI# TNMU160508R-G27 WKP35GCat# TNMU160508R-G27 WKP35GSeries TNMU
$47.22List $59.51
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
Sold in multiples of 10 — minimum order 10
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeTriangle
GradeWKP35G
MaterialCarbide
CoatingTiAlN/TiN
Description
The Walter 8209399 is a TNMU160508R-G27 WKP35G carbide indexable insert, grade WKP35G, TiAlN/TiN coated. Suited for steel, cast iron.
Specifications
Chip breakerG27
Coating finishTiAlN/TiN
Coating processCVD
Corner radius0.0315
Cutting directionRight Hand
Inscribed circle0.3780
Insert handRight Hand
Insert holding methodScrew
Insert materialCarbide
Insert shapeTriangle
Insert size160508
Insert size code16
Insert styleTNMU
Iso codeTNMU160508R-G27 WKP35G
Manufacturers catalog numberTNMU160508R-G27 WKP35G
Manufacturer gradeWKP35G
Number of cutting edges6
Primary workpiece materialSteel; Cast Iron
Relief angle0.000
Single or double sided insertDouble
Thickness0.2106
Width0.3779
