Walter-Prototyp
0.1570in" 3-Flute Solid Carbide Corner Radius End Mill, TiAlN - Walter-Prototyp 6579418
MFR# 6579418Series MC326
$124.26List $156.60
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
MaterialSolid Carbide
CoatingTiAlN
Description
The Walter-Prototyp 6579418 is a 0.1570in 3-flute Solid Carbide corner radius end mill with a TiAlN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium. 2in overall length. Series MC326.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishTiAlN
Coolant throughNo
Corner radius0.0390
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachYes
Flute directionRight Hand
Flute typeSpiral
For use withToolholders
Helix styleHigh
Length of cut0.2790in
Length typeLong
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
Material removal typeRoughing & Finishing
Mill diameter0.1570in
Mill diameter toleranceh9
Neck diameter0.1500in
Number of flutes3
Overall length in2in
PitchCoarse
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
Reach length0.5910
Secondary workpiece materialCast Iron; Hard Material; Stainless Steel
Shank diameter (mm)6.00mm
Shank diameter toleranceh5
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexNo
