0.1970in" 3-Flute Solid Carbide Corner Radius End Mill, TiAlN - Walter-Prototyp 6579469

Walter-Prototyp

0.1970in" 3-Flute Solid Carbide Corner Radius End Mill, TiAlN - Walter-Prototyp 6579469

MFR# 6579469Series MC326

$101.04List $129.60 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes3
MaterialSolid Carbide
CoatingTiAlN

Description

The Walter-Prototyp 6579469 is a 0.1970in 3-flute Solid Carbide corner radius end mill with a TiAlN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium. 2in overall length. Series MC326.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishTiAlN
Coolant throughNo
Corner radius0.0200
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachYes
Flute directionRight Hand
Flute typeSpiral
For use withToolholders
Helix styleHigh
Length of cut3.0000in
Length typeLong
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
Material removal typeRoughing & Finishing
Mill diameter0.1970in
Mill diameter toleranceh9
Neck diameter0.1870in
Number of flutes3
Overall length in2in
PitchCoarse
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
Reach length0.6300
Secondary workpiece materialCast Iron; Hard Material; Stainless Steel
Shank diameter (mm)6.00mm
Shank diameter toleranceh5
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexNo
