Walter-Prototyp
5/16-24 UNF Cobalt Tap, Vaporisiert - Walter-Prototyp 7557108
MFR# 7557108Series TC117
$76.32List $94.60
Save 19%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
Thread size5/16-24
CoatingVaporisiert
Description
The Walter-Prototyp 7557108 is a 5/16-24 UNF Cobalt tap with a Vaporisiert finish. 3 flutes.
Specifications
ApplicationBlind Hole Threading
ChamferBottoming
Class of fit2B/3B
Coating finishVaporisiert
Coolant throughNo
Flute directionRight Hand
Flute styleSpiral
Helix angle40
MaterialCobalt
Material applicationCast Iron; Non-Ferrous Metal; Stainless Steel; Steel
Material gradeWY80FC
Number of flutes3
Overall length (mm)90.00
OversizeNo
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Aluminum & Non-Ferrous
Shank diameter0.3180
Square length0.3800
Square size0.2380
Tapping depth1.3780
Threads per inch24
Thread directionRight Hand
Thread length0.4720
Thread size in5/16-24
Thread standardUNF
