Walter-Prototyp
1/4-20 UNC High-Speed Steel Tap, TiN - Walter-Prototyp 7606556
MFR# 7606556Series TC115
$26.73List $33.70
Save 20%
Stock and current price confirmed on request. Ask us →
We check the supplier's stock and today's price for this item before you order, and reply the same business day.
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
Thread size1/4-20
CoatingTiN
Description
The Walter-Prototyp 7606556 is a 1/4-20 UNC High-Speed Steel tap with a TiN finish. 3 flutes.
Specifications
ApplicationBlind Hole Threading
ChamferSemi-Bottoming
Class of fit2B
Coating finishTiN
Coolant throughNo
Flute directionRight Hand
Flute styleSpiral
Helix angle45
MaterialHigh-Speed Steel
Material applicationCast Iron; Non-Ferrous Metal; Stainless Steel; Steel
Number of flutes3
Overall length (mm)80.00
OversizeNo
Shank diameter (mm)6.48
Square length0.3130
Square size0.1910
Tapping depth1.1810
Threads per inch20
Thread directionRight Hand
Thread length0.3940
Thread size in1/4-20
Thread standardUNC
