Widia
CNMG190612 Carbide Insert, Grade THM - Widia 2559382
MFR# 2559382ISO/ANSI# CNMG643Series CNMG
$19.45List $24.94
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/4
ShapeRhombic
GradeTHM
MaterialCarbide
Description
The Widia 2559382 is a CNMG190612 carbide indexable insert, grade THM. Suited for non-ferrous metal.
Specifications
Clearance codeN
Coating processUncoated
Corner radius in3/64
Cutting edge styleHoned
Full radiusNo
Hole diameter0.3125
Included angle80
Industry standard numberCNMG643
Inscribed circle in3/4
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.7616
Insert materialCarbide
Insert shapeRhombic
Insert size code643
Insert styleCNMG
Insert thickness in1/4
Iso codeCNMG190612
Length range0.7000 - 10.0000
Manufacturers catalog number2559382
Manufacturer gradeTHM
Material gradeK15
Maximum depth of cut0.2539
Multi use applicationTurning
Multi use toolNo
Number of cutting edges8
Primary workpiece materialNon-Ferrous Metal
RakeNegative
Relief angle0
Secondary workpiece materialCast Iron; Super-alloys & Titanium
StandardsANSI; ISO
Tolerance codeM
Width in3/4
Wiper edgeNo
