GCHT060202 Carbide Insert, Grade CG5, TiN - Widia 2827537

Widia

GCHT060202 Carbide Insert, Grade CG5, TiN - Widia 2827537

MFR# 2827537ISO/ANSI# GCHT151505Series GCHT

$23.68List $30.38 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeRhombic
GradeCG5
MaterialCarbide
CoatingTiN

Description

The Widia 2827537 is a GCHT060202 carbide indexable insert, grade CG5, TiN coated. Suited for steel, stainless steel, non-ferrous metal, superalloys & titanium.

Specifications

Clearance codeC
Coating finishTiN
Coating processPVD
Corner radius0.0070
Cutting edge styleHoned
Full radiusNo
Hole diameter0.0940
Included angle45degree
Industry standard numberGCHT151505
Inscribed circle0.1902
Insert handNeutral
Insert holding methodScrew
Insert length0.2690
Insert materialCarbide
Insert shapeRhombic
Insert size code151505
Insert styleGCHT
Insert thickness0.0930
Iso codeGCHT060202
Length range0.0000 - 0.3000
Manufacturers catalog number2827537
Manufacturer gradeCG5
Material gradeSubmicron
Maximum depth of cut0.0897
Multi use applicationTurning
Multi use toolNo
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Non-Ferrous Metal; Superalloys & Titanium
RakePositive
Relief angle7
Secondary workpiece materialCast Iron
StandardsANSI; ISO
Tolerance codeH
Width0.1902in
Wiper edgeNo
