Widia
GPHT050102 Carbide Insert, Grade CG5, TiN - Widia 2827560
MFR# 2827560ISO/ANSI# GPHT050102Series GPHT
$23.68List $30.38
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC5/32
GradeCG5
MaterialCarbide
CoatingTiN
Description
The Widia 2827560 is a GPHT050102 carbide indexable insert, grade CG5, TiN coated. Suited for steel, stainless steel, cast iron, non-ferrous metal.
Specifications
ApplicationsProfiling; Turning
ChipbreakerNone
Coating finishTiN
Coating processPVD
Corner radius0.0070
Hole diameter0.0840
Included angle45
Inscribed circle in5/32
Insert handNeutral
Insert height0.0620
Insert holding methodClamp; Pin
Insert length0.2270
Insert materialCarbide
Insert size code12105
Insert styleGPHT
Iso codeGPHT050102
Manufacturer gradeCG5
Material gradeP10; M10; K10; N10
Maximum depth of cut0.0757
Msc manufacturer numberGPHT12105
Number of cutting edges2
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal
RakePositive
Relief angle11
Secondary workpiece materialCast Iron
ShapeParallelogram
Side length0.2270
StandardsGPHT12105; GPHT050102
Thickness0.0620
Width in5/32
