GCHW060202 Carbide Insert, Grade CG5, TiN - Widia 2827596

Widia

GCHW060202 Carbide Insert, Grade CG5, TiN - Widia 2827596

MFR# 2827596ISO/ANSI# GCHWSeries GCHW

$19.56List $25.09 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC3/16
ShapeNon-ISO Specialty Shapes
GradeCG5
MaterialCarbide
CoatingTiN

Description

The Widia 2827596 is a GCHW060202 carbide indexable insert, grade CG5, TiN coated. Suited for steel, stainless steel, non-ferrous metal, superalloys & titanium.

Specifications

Ansi insert codeGCHW151505
Ansi size code151505
Clearance codeC
Coating finishTiN
Coating processPVD
Corner radius0.0070
Cutting edge styleHoned
Full radiusNo
Hole diameter0.0940
Included angle45
Industry standard numberGCHW151505
Inscribed circle in3/16
Insert handNeutral
Insert holding methodScrew
Insert length0.2650
Insert materialCarbide
Insert shapeNon-ISO Specialty Shapes
Insert size code151505
Insert styleGCHW
Insert thickness0.0930
Iso codeGCHW060202
Iso insert codeGCHW
Length range0.0000 - 0.3000
Manufacturers catalog number2827596
Manufacturer gradeCG5
Material gradeSubmicron
Maximum depth of cut0.0883
Multi use applicationTurning
Multi use toolNo
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Non-Ferrous Metal; Superalloys & Titanium
RakePositive
Relief angle7
Secondary workpiece materialCast Iron
Side clearancePositive
StandardsANSI; ISO
Tolerance codeH
Width in3/16
Wiper edgeNo
