Widia

5/8" 4-Flute Solid Carbide Corner Radius & Corner Chamfer End Mill, TiCN - Widia 3320946

MFR# 3320946Cat# TC4S1R16006Series 4S0R

$312.56List $400.87 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter5/8

Flutes4

MaterialSolid Carbide

CoatingTiCN

Description

The Widia 3320946 is a 5/8 4-flute Solid Carbide corner radius & corner chamfer end mill with a TiCN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 2-1/4 length of cut, 5 overall length. Series 4S0R.

Specifications

CentercuttingYes

Chamfer angle45

Chamfer length0.0197

Chamfer width0.0197

ChipbreakerYes

Coating finishTiCN

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeHelical

Helix styleMedium

Length of cut in2-1/4

Length typeRegular

Manufacturers catalog numberTC4S1R16006

Material removal typeRoughing

Mill diameter in5/8

Number of flutes4

Overall length in5

PitchNormal

Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material

Reach length in2-1/4

Shank diameter in5/8

Shank typeWeldon Flat

Single or double endSingle

Variable helixNo

Variable indexNo
