Widia
Indexable Grooving - Widia 3655918
MFR# 3655918Series WMT
$166.54List $176.93
Save 5%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Widia 3655918 indexable grooving. Suited for universal. Series WMT.
Specifications
Back of bar to cutting edge1.0000
Compatible insert size codeS125
Coolant throughNo
Cutting tool applicationGrooving; Cut-Off; Turning
Hand of holderRight Hand
Head height (mm)33.330
Head length1.6252
Insert compatibilityWMTS125I3P08
Insert holding methodClamp
Insert seat size3.0
Internal or externalExternal
Maximum depth of cut0.8750
Maximum groove width0.1250
Minimum groove width0.1180
Overall length6.0000
Primary workpiece materialUniversal
Shank height in1
Shank length4.3750
Shank width diameter in1
Toolholder styleWMTSR
Tool materialSteel
