Widia
WMTC125N00CM17 Carbide Insert, Grade WU25PT, AlTiN - Widia 4169582
MFR# 4169582ISO/ANSI# WMTC125N00CM17Cat# WMTC125N00CM17Series WMTC
$38.43List $49.29
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeWU25PT
MaterialCarbide
CoatingAlTiN
Description
The Widia 4169582 is a WMTC125N00CM17 carbide indexable insert, grade WU25PT, AlTiN coated. Suited for super-alloys & titanium.
Specifications
Ansi codeWMTC125N00CM17
ChipbreakerCM
Coating finishAlTiN
Coating processPVD
Corner radius0.0070
Cutting directionNeutral
Cutting height0.1850
Cutting tool applicationCut-Off
Cutting width in1/8
Insert handNeutral
Insert holding methodClamp
Insert materialCarbide
Insert seat size3
Insert size code125N
Insert styleWMTC
Insert width0.0940
Iso codeWMTC125N00CM17
Lead angle0
Lead angle directionNeutral
Manufacturers catalog numberWMTC125N00CM17
Manufacturer gradeWU25PT
Maximum depth of cut1.0000
Multi use toolNo
Overall length1.0000
Overall width0.1250
Primary workpiece materialSuper-alloys & Titanium
Relief angle5.000
Secondary workpiece materialNon-Ferrous Metal; Cast Iron; Stainless Steel; Steel
Single or double endDouble
