Widia
CNMG120404ML Carbide Insert, Grade WP25CT, TiN - Widia 4170458
MFR# 4170458ISO/ANSI# CNMG431MLSeries CNMG-ML
$7.53List $9.65
Save 21%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeRhombic
GradeWP25CT
MaterialCarbide
CoatingTiN
Description
The Widia 4170458 is a CNMG120404ML carbide indexable insert, grade WP25CT, TiN coated. Suited for steel, cast iron.
Specifications
Chip breakerML
Clearance codeN
Coating finishTiN
Coating processMTCVD
Corner radius in1/64
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2031
Included angle80
Industry standard numberCNMG431ML
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.5077
Insert materialCarbide
Insert shapeRhombic
Insert size code431
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG120404ML
Length range0.5000 - 0.6000
Manufacturers catalog number4170458
Manufacturer gradeWP25CT
Material gradeP25
Maximum depth of cut0.1580
Multi use applicationTurning
Multi use toolNo
Number of cutting edges8
Primary workpiece materialSteel; Cast Iron
RakeNegative
Rake angle10
Relief angle0
Secondary workpiece materialCast Iron
StandardsANSI; ISO
Tolerance codeM
Width in1/2
Wiper edgeNo
