Widia
CNMG120408MR Carbide Insert, Grade WP25CT, TiN - Widia 4170547
MFR# 4170547ISO/ANSI# CNMG432MRSeries CNMG-MR
$9.02List $11.57
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeRhombic 80
GradeWP25CT
MaterialCarbide
CoatingTiN
Description
The Widia 4170547 is a CNMG120408MR carbide indexable insert, grade WP25CT, TiN coated. Suited for steel, cast iron.
Specifications
Chip breakerMR
Clearance codeN
Coating finishTiN
Coating processMTCVD
Corner radius in1/32
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2031
Included angle80degree
Industry standard numberCNMG432MR
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.5077
Insert materialCarbide
Insert shapeRhombic 80
Insert size code432
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG120408MR
Length range0.5000 - 0.6000
Manufacturers catalog number4170547
Manufacturer gradeWP25CT
Material gradeP25
Maximum depth of cut0.4568
Multi use applicationTurning
Multi use toolNo
Number of cutting edges8
Primary workpiece materialSteel; Cast Iron
RakeNegative
Relief angle0
Secondary workpiece materialCast Iron
StandardsANSI; ISO
Tolerance codeM
Width in1/2in
Wiper edgeNo
