Widia
CNMG120408MR Carbide Insert, Grade WP15CT, TiN - Widia 4171131
MFR# 4171131ISO/ANSI# CNMG432MRSeries CNMG-MR
$9.02List $11.57
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeRhombic 80
GradeWP15CT
MaterialCarbide
CoatingTiN
Description
The Widia 4171131 is a CNMG120408MR carbide indexable insert, grade WP15CT, TiN coated. Suited for steel.
Specifications
Chip breakerMR
Clearance codeN
Coating finishTiN
Coating processMTCVD
Corner radius in1/32
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2031
Included angle80degree
Industry standard numberCNMG432MR
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.5077
Insert materialCarbide
Insert shapeRhombic 80
Insert size code432
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG120408MR
Length range0.5000 - 0.6000
Manufacturers catalog number4171131
Manufacturer gradeWP15CT
Material gradeP15
Maximum depth of cut0.4568
Multi use applicationTurning
Multi use toolNo
Number of cutting edges8
Primary workpiece materialSteel
RakeNegative
Relief angle0
Secondary workpiece materialCast Iron
StandardsANSI; ISO
Tolerance codeM
Width in1/2in
Wiper edgeNo
