Widia
CNMG120404FF Carbide Insert, Grade WK20CT, TiN - Widia 4171318
MFR# 4171318ISO/ANSI# CNMG431FFSeries CNMG-FF
$9.02List $11.57
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeRhombic 80
GradeWK20CT
MaterialCarbide
CoatingTiN
Description
The Widia 4171318 is a CNMG120404FF carbide indexable insert, grade WK20CT, TiN coated. Suited for cast iron.
Specifications
Chip breakerFF
Clearance codeN
Coating finishTiN
Coating processMTCVD
Corner radius in1/64
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2031
Included angle80degree
Industry standard numberCNMG431FF
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.5079
Insert materialCarbide
Insert shapeRhombic 80
Insert size code431
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG120404FF
Length range0.5000 - 0.6000
Manufacturers catalog number4171318
Manufacturer gradeWK20CT
Maximum depth of cut0.1230
Multi use applicationTurning
Multi use toolNo
Number of cutting edges8
Primary workpiece materialCast Iron
RakeNegative
Rake angle12
Relief angle0
Secondary workpiece materialSteel
StandardsANSI; ISO
Tolerance codeM
Width in1/2in
Wiper edgeNo
