Widia
CNMG120408RH Carbide Insert, Grade WP25CT, TiN - Widia 4171504
MFR# 4171504ISO/ANSI# CNMG432RHSeries CNMG-RH
$10.65List $13.42
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
Sold in multiples of 5 — minimum order 5
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeRhombic 80
GradeWP25CT
MaterialCarbide
CoatingTiN
Description
The Widia 4171504 is a CNMG120408RH carbide indexable insert, grade WP25CT, TiN coated. Suited for steel, cast iron.
Specifications
Chip breakerRH
Clearance codeN
Coating finishTiN
Coating processMTCVD
Corner radius in1/32
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2031
Included angle80degree
Industry standard numberCNMG432RH
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.5077
Insert materialCarbide
Insert shapeRhombic 80
Insert size code432
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG120408RH
Length range0.5000 - 0.6000
Manufacturers catalog number4171504
Manufacturer gradeWP25CT
Material gradeP25
Maximum depth of cut0.1692
Multi use applicationTurning
Multi use toolNo
Number of cutting edges8
Primary workpiece materialSteel; Cast Iron
RakeNegative
Relief angle0
Secondary workpiece materialCast Iron
StandardsANSI; ISO
Tolerance codeM
Width in1/2in
Wiper edgeNo
