Widia
CNMG120408MR Carbide Insert, Grade WM25CT, TiN - Widia 4172955
MFR# 4172955ISO/ANSI# CNMG432MRSeries CNMG-MR
$9.02List $11.57
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeRhombic 80
GradeWM25CT
MaterialCarbide
CoatingTiN
Description
The Widia 4172955 is a CNMG120408MR carbide indexable insert, grade WM25CT, TiN coated. Suited for stainless steel.
Specifications
Chip breakerMR
Clearance codeN
Coating finishTiN
Coating processMTCVD
Corner radius in1/32
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2031
Included angle80
Industry standard numberCNMG432MR
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.5077
Insert materialCarbide
Insert shapeRhombic 80
Insert size code432
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG120408MR
Length range0.5000 - 0.6000
Manufacturers catalog number4172955
Manufacturer gradeWM25CT
Material gradeM25
Maximum depth of cut0.4568
Multi use applicationTurning
Multi use toolNo
Number of cutting edges8
Primary workpiece materialStainless Steel
RakeNegative
Relief angle0
Secondary workpiece materialSteel; Super-alloys & Titanium
StandardsANSI; ISO
Tolerance codeM
Width in1/2
Wiper edgeNo
