Widia
TCF120405ECV36 Carbide Insert, Grade WU40PH, TiAlN - Widia 5538607
MFR# 5538607ISO/ANSI# TCF120405ECV36Series TCF
$15.91List $20.40
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeWU40PH
MaterialCarbide
CoatingTiAlN
Description
The Widia 5538607 is a TCF120405ECV36 carbide indexable insert, grade WU40PH, TiAlN coated. Suited for steel, high temperature alloys.
Specifications
Ansi codeTCF120405ECV36
ChipbreakerV36
Coating finishTiAlN
Coating processPVD
Compatible drill styleTCF
Corner radius0.0197
Hole diameter0.1339in
Included angle degree90
Inscribed circle0.4725
Insert handNeutral
Insert materialCarbide
Insert size12
Insert size code120405
Insert styleTCF
Iso codeTCF120405ECV36
Length0.3858
Manufacturer gradeWU40PH
Number of cutting edges4
Primary workpiece materialSteel; High Temperature Alloys
RakePositive
Relief angle11
ShapeIrregular
Thickness0.1417
Width0.3858
