Widia
TCF100408EPV36 Carbide Insert, Grade WU25CH, TiCN - Widia 5538611
MFR# 5538611ISO/ANSI# TCF100408EPV36Series TCF
$14.53List $18.64
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeWU25CH
MaterialCarbide
CoatingTiCN
Description
The Widia 5538611 is a TCF100408EPV36 carbide indexable insert, grade WU25CH, TiCN coated. Suited for steel.
Specifications
Ansi codeTCF100408EPV36
ChipbreakerV36
Coating finishTiCN
Coating processCVD
Compatible drill styleTCF
Corner radius in1/32
Hole diameter0.1339in
Included angle degree90
Inscribed circle0.3922
Insert handNeutral
Insert materialCarbide
Insert size10
Insert size code100408
Insert styleTCF
Iso codeTCF100408EPV36
Length0.4173
Manufacturer gradeWU25CH
Number of cutting edges4
Primary workpiece materialSteel
RakePositive
Relief angle11
ShapeIrregular
Thickness0.1417
Width0.4173
