Widia
TCF150512GPV34 Carbide Insert, Grade WU40PH, TiAlN - Widia 5542600
MFR# 5542600ISO/ANSI# TCF150512GPV34Series TCF
$17.93List $23.00
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeWU40PH
MaterialCarbide
CoatingTiAlN
Description
The Widia 5542600 is a TCF150512GPV34 carbide indexable insert, grade WU40PH, TiAlN coated. Suited for steel, high temperature alloys.
Specifications
Ansi codeTCF150512GPV34
ChipbreakerV34
Coating finishTiAlN
Coating processPVD
Compatible drill styleTCF
Corner radius in3/64
Hole diameter0.2362in
Included angle degree90
Inscribed circle0.5957
Insert handNeutral
Insert materialCarbide
Insert size15
Insert size code150512
Insert styleTCF
Iso codeTCF150512GPV34
Length0.6339
Manufacturer gradeWU40PH
Number of cutting edges4
Primary workpiece materialSteel; High Temperature Alloys
RakePositive
Relief angle11
ShapeIrregular
Thickness0.2126
Width0.6339
