Widia
7/8-14 UNF Cobalt Tap, Oxide - Widia 6172920
MFR# 6172920Series VTSFT-TC
$145.01List $185.98
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes4
Thread size7/8-14
CoatingOxide
Description
The Widia 6172920 is a 7/8-14 UNF Cobalt tap with a Oxide finish. 4 flutes.
Specifications
ChamferModified Bottoming
Class of fit2B
Coating finishOxide
Coolant throughNo
Flute directionRight Hand
MaterialCobalt
Material applicationSteel; Stainless Steel; Cast Iron
Material gradeWP49EG
Number of flutes4
Overall length4.9200
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Aluminum & Non-Ferrous
Shank diameter0.7087
Square size0.5710
Tapping depth2.2400
Threads per inch14
Thread directionRight Hand
Thread length0.7100
Thread limitH6
Thread pitch0.0714
Thread size in7/8-14
Thread standardUNF
