Widia
1-8 UNC Cobalt Tap, Oxide - Widia 6172933
MFR# 6172933Series VTSFT-TC
$222.35List $285.17
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes4
Thread size1-8
CoatingOxide
Description
The Widia 6172933 is a 1-8 UNC Cobalt tap with a Oxide finish. 4 flutes.
Specifications
ChamferModified Bottoming
Class of fit2B
Coating finishOxide
Coolant throughNo
Flute directionRight Hand
MaterialCobalt
Material applicationSteel; Stainless Steel; Cast Iron
Material gradeWP49EG
Number of flutes4
Overall length6.3000
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Aluminum & Non-Ferrous
Shank diameter0.7087
Square size0.5710
Tapping depth3.5000
Threads per inch8
Thread directionRight Hand
Thread length1.1800
Thread limitH6
Thread pitch0.1250
Thread size in1-8
Thread standardUNC
