CCGT060204AL Carbide Insert, Grade WU10HT - Widia 6846529

Widia

CCGT060204AL Carbide Insert, Grade WU10HT - Widia 6846529

MFR# 6846529ISO/ANSI# CCGT060204Series CCGT-AL

$20.31List $26.05 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/4
ShapeC - Diamond (Rhombic) 80-Deg
GradeWU10HT
MaterialCarbide

Description

The Widia 6846529 is a CCGT060204AL carbide indexable insert, grade WU10HT. Suited for non-ferrous metal.

Specifications

Ansi insert codeCCGT2151
Ansi size code2151
Chip breakerAL
Clearance codeC
Coating processUncoated
Corner radius in1/64
Cutting edge styleHoned
Full radiusNo
Grade characteristicsStainless Steel (M) - High Wear-Resistance; Cast Iron (K) - High Wear-Resistance; Aluminum & Non-Ferrous (N) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Special, Super Alloys (S) - High Wear-Resistance; Hardened Materials (H) - High
Hole diameter0.1100
Included angle80
Industry standard numberCCGT2151AL
Inscribed circle in1/4
Insert handNeutral
Insert holding methodScrew
Insert length0.2548
Insert materialCarbide
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code2151
Insert styleCCGT
Insert thickness in3/32
Iso codeCCGT060204AL
Iso insert codeCCGT060204
Iso size code060204
Length range0.0000 - 0.3000
Manufacturers catalog number6846529
Manufacturer gradeWU10HT
Material gradeN10
Maximum depth of cut0.0849
Multi use applicationTurning; Facing; Chamfering; Profiling; Boring
Multi use toolYes
Number of cutting edges4
Primary workpiece materialNon-Ferrous Metal
RakePositive
Relief angle7
Side clearancePositive
StandardsANSI; ISO
Tolerance codeG
Width in1/4
Wiper edgeNo
