Widia

1/2" 3-Flute Solid Carbide Corner Radius End Mill - Widia 6853288

MFR# 6853288Series 3A29

$118.74List $152.29 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/2

Flutes3

MaterialSolid Carbide

CoatingBright/Uncoated

Description

The Widia 6853288 is a 1/2 3-flute Solid Carbide corner radius end mill. Suited for non-ferrous metal. 2-1/4 length of cut, 4-1/2 overall length. Series 3A29.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishBright/Uncoated

Coolant throughNo

Corner radius0.1200

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

For use withToolholders

Length of cut in2-1/4

Length typeLong

Material applicationNon-Ferrous Metal

Material removal typeRoughing & Finishing

Mill diameter in1/2

Neck diameter0

Number of flutes3

Overall length in4-1/2

PitchNormal

Primary workpiece materialNon-Ferrous Metal

Reach length in2-1/4

Shank diameter in1/2

Shank typeStraight-Cylindrical

Single or double endSingle

Variable helixYes

Variable indexNo
