Widia
1/8" 4-Flute Solid Carbide Ball End Mill, TiAlN - Widia 6945890
MFR# 6945890Cat# W40BE03000RBTSeries W40B
$16.79List $21.54
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter1/8
Flutes4
MaterialSolid Carbide
CoatingTiAlN
Description
The Widia 6945890 is a 1/8 4-flute Solid Carbide (WU20PE) ball end mill with a TiAlN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 1/2 length of cut, 2 overall length. Series W40B.
Specifications
ChipbreakerNo
Coating finishTiAlN
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix styleVariable
Length of cut in1/2
Length typeStandard
Manufacturers catalog numberW40BE03000RBT
Material gradeWU20PE
Material removal typeRoughing & Finishing
Mill diameter in1/8
Neck length0.0000
Nose radius0.0625
Number of flutes4
Overall length in2
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Reach length in1/2
Secondary workpiece materialCast Iron
Shank diameter in1/8
Shank typeStraight-Cylindrical
Single or double endSingle
System of measurementFractional Inch
Variable helixYes
Variable indexYes
