ODMT060508-YG602 Solid Carbide Insert, Grade YG602, TiAlN - YG-1 12000030

YG-1

ODMT060508-YG602 Solid Carbide Insert, Grade YG602, TiAlN - YG-1 12000030

MFR# 12000030ISO/ANSI# ODMT060508-YG602Cat# ODMT060508-YG602Series ODMT

$15.38List $19.73 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeOctagon
GradeYG602
MaterialSolid Carbide
CoatingTiAlN

Description

The YG-1 12000030 is a ODMT060508-YG602 solid carbide indexable insert, grade YG602, TiAlN coated. Suited for steel, stainless steel, cast iron, superalloys & titanium.

Specifications

Ansi codeODMT060508-YG602
Chip breakerCommon
Coating finishTiAlN
Coating processPVD
Corner radius in1/32
Cutter series compatibilityF43-OD
Cutting edge styleChamfered; Honed
Included angle degree135
Inscribed circle0.6260
Inscribed circle range0.6000 to 0.7000
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeOctagon
Insert size06
Insert size code060508
Insert styleODMT
Iso codeODMT060508-YG602
Length in5/8
Length range0.6000 to 0.6500
Manufacturers catalog numberODMT060508-YG602
Manufacturer gradeYG602
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
Material gradeP20; M20; K20; S15
Multi use toolNo
Number of cutting edges8
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
RakePositive
Relief angle15.00
Single or double sided insertSingle
StandardsANSI; ISO
Thickness0.2200
Thickness range0.2200 to 0.2350
Width in5/8
