Yuasa
Collet Fixture - Yuasa 550-007
MFR# 550-007
$2,784.92List $3,147.55
Save 11%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Yuasa 550-007 is a collet fixture.
Specifications
Centerline height5.8700
Chuck diameter in8
Chuck through hole size2.4800
Concentricity of chuck0.0005
Face plate diameter10.0000
Face plate diameter frac in10
Includes chuckYes
Indexing accuracy25 s
Masking plate divisions12; 2; 3; 4; 6; 8
Number of indexing increments24
Overall height10.1200
Overall length6.8200
Overall width12.2800
Parallelism over face0.0006
Spacer typeSuper
Squareness base to chuck0.0008
