0.0780" 2-Flute Solid Carbide Corner Radius End Mill - Harvey Tool 51378

Harvey Tool

0.0780" 2-Flute Solid Carbide Corner Radius End Mill - Harvey Tool 51378

MFR# 51378Series Miniature End Mills - Corner Radius - Stub & Standard; Miniature End Mills

$33.54List $39.16 Save 14%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes2
MaterialSolid Carbide
CoatingUncoated

Description

The Harvey Tool 51378 is a 0.0780 2-flute Solid Carbide corner radius end mill. Suited for steel, stainless steel, cast iron, non-ferrous metal, non-iso. 15/64 length of cut, 1-1/2 overall length. Series Miniature End Mills - Corner Radius - Stub & Standard; Miniature End Mills.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishUncoated
Coolant throughNo
Corner radius0.0200
Corner radius tolerance0.0010 to -0.0010 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeHelical
For use withToolholder
Length of cut in15/64
Length typeRegular
Material applicationAluminum; Cast Iron; Steel; Stainless Steel; Wood; Composite
Material removal typeRoughing & Finishing
Mill diameter0.0780
Mill diameter tolerance0.0005 to -0.0005 in
Number of flutes2
Overall length in1-1/2
Overall length tolerance0.0100 to -0.0000 in
PitchCoarse
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Non-ISO
Shank diameter in1/8
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexNo
