Helical Solutions

3/4" 7-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 82924

MFR# 82924Series HEV-C-7

$468.08List $546.48 Save 14%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/4

Flutes7

MaterialSolid Carbide

CoatingTplus

Description

The Helical Solutions 82924 is a 3/4 7-flute Solid Carbide corner radius end mill with a Tplus finish for longer tool life. Suited for steel, stainless steel, cast iron. 2-1/4 length of cut, 5 overall length. Series HEV-C-7.

Specifications

CentercuttingYes

ChipbreakerYes

Coating finishTplus

Coolant throughNo

Corner radius0.0300

Corner radius tolerance-0.0020 to 0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

For use withHigh Precision Toolholders

Length of cut in2-1/4

Length typeStandard

Material applicationStainless Steel; High-Temperature Alloy; Hardened Steel

Material removal typeRoughing

Mill diameter in3/4

Mill diameter tolerance-0.0020/0.0000 in

Number of flutes7

Overall length in5

Overall length tolerance-0.0620/0.0620 in

PitchVariable

Primary workpiece materialSteel; Stainless Steel; Cast Iron

Secondary workpiece materialNon-Ferrous Metal; Superalloys & Titanium

Shank diameter in3/4

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Tir maximum0.0005

Variable helixNo

Variable indexYes
