1/2" 5-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 83106

Helical Solutions

1/2" 5-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 83106

MFR# 83106Series HEV-C-5

$162.44List $189.64 Save 14%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2
Flutes5
MaterialSolid Carbide
CoatingTplus

Description

The Helical Solutions 83106 is a 1/2 5-flute Solid Carbide corner radius end mill with a Tplus finish for longer tool life. Suited for stainless steel, high temperature alloy, hard material. 1-1/4 length of cut, 3 overall length. Series HEV-C-5.

Specifications

CentercuttingYes
ChipbreakerYes
Coating finishTplus
Coolant throughNo
Corner radius0.0300
Corner radius tolerance-0.0020 to 0.0020 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeHelical
For use withHigh Precision Toolholder
Length of cut in1-1/4
Length typeRegular
Material applicationStainless Steel; High-Temperature Alloy; Hardened Steel
Material removal typeRoughing
Mill diameter in1/2
Mill diameter tolerance-0.0020 to 0.0000 in
Number of flutes5
Overall length in3
Overall length tolerance-0.0620 to 0.0620 in
PitchVariable
Primary workpiece materialStainless Steel; High Temperature Alloy; Hard Material
Secondary workpiece materialSteel; Cast Iron
Shank diameter in1/2
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Tir maximum0.0005
Variable helixNo
Variable indexYes
