Iscar
Indexable Drilling - Iscar 3202947
MFR# 3202947Series SumoCham
$308.60List $318.30
Save 3%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Iscar 3202947 indexable drilling. Series SumoCham.
Specifications
Body length2.0700in
Compatible insert styleFCP; ICK; ICK-2M; ICM; ICN; ICP; iCP-2M
Coolant throughYes
Drill depth by diameter ratio5xD
Insert seat size7
Maximum drill depth1.4800
Maximum drill depth range0.0000 to 1.5000
Maximum drill diameter0.3110
Minimum drill diameter0.2950
Overall length3.8400in
Shank diameter in1/2in
Shank length1.7700in
Shank typeWeldon Flat
StandardsISO 13399
Toolholder styleDCN
Tool applicationHolemaking
