Iscar

1/2" 3-Flute Solid Carbide Corner Radius & Corner Chamfer End Mill, AlTiN - Iscar 5620947

MFR# 5620947Cat# ECSI-E-3 500-562-C500Series ECSI-E-3

$92.30List $118.20 Save 21%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/2

Flutes3

MaterialSolid Carbide

CoatingAlTiN

Description

The Iscar 5620947 is a 1/2 3-flute Solid Carbide (IC900) corner radius & corner chamfer end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, cast iron. 5/9 length of cut, 3 overall length. Series ECSI-E-3.

Specifications

Additional informationShouldering; Slotting; Rampdown; Helical Interpolation; Drill Mill; Plunging & Recessing

CentercuttingYes

ChipbreakerNo

Coating finishAlTiN

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachYes

Flute directionRight Hand

Flute typeHelical

Helix angle38

Helix styleMedium

Length of cut in5/9

Length typeShort

Manufacturers catalog numberECSI-E-3 500-562-C500

Material gradeIC900

Material removal typeRoughing & Finishing

Mill diameter in1/2

Neck diameter0.4700

Number of flutes3

Overall length in3

PitchNormal

Primary workpiece materialSteel; Stainless Steel; Cast Iron

Reach length in1

Secondary workpiece materialNon-Ferrous Metal; Superalloys & Titanium; Hard Material

Shank diameter in1/2

Shank typeStraight-Cylindrical

Single or double endSingle

Variable helixNo

Variable indexNo
