Kennametal
3/8" 2-Flute Solid Carbide Corner Radius End Mill, PCD - Kennametal 6752756
MFR# 6752756Cat# ALCC2RA0375N063HAR010ISeries ALCC
$504.93List $647.60
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter3/8
Flutes2
MaterialSolid Carbide
CoatingPCD
Description
The Kennametal 6752756 is a 3/8 2-flute Solid Carbide corner radius end mill with a PCD finish for longer tool life. Suited for non-ferrous metal. 5/8 length of cut, 3 overall length. Series ALCC.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishPCD
Coolant throughYes
Corner radius0.0100
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeHelical
For use withHC 20M - HC 32M Hydraulic Sleeves Metric with Inch Bores
Length of cut in5/8
Length typeShort
Manufacturers catalog numberALCC2RA0375N063HAR010I
Material applicationNon-Ferrous Metal
Material removal typeRoughing
Mill diameter in3/8
Neck diameter0.3386
Number of flutes2
Overall length in3
PitchCoarse
Primary workpiece materialNon-Ferrous Metal
Reach length (mm)34.00
Shank diameter in3/8
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexNo
