1" 4-Flute Solid Carbide Corner Radius End Mill - M.A. Ford. 11110002

MFR# 11110002Series 111

$517.81List $664.11 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1

Flutes4

MaterialSolid Carbide

CoatingUncoated

Description

The M.A. Ford. 11110002 is a 1 4-flute Solid Carbide (Micrograin) corner radius end mill. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material. 1-1/2 length of cut, 4 overall length. Series 111.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishUncoated

Coolant throughNo

Corner radius0.0200

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

For use withToolholder

Helix angle30

Helix styleMedium

Length of cut in1-1/2

Length typeRegular

Manufacturers catalog number11110002

Material applicationSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material

Material gradeMicrograin

Material removal typeRoughing & Finishing

Maximum helix angle30

Mill diameter in1

Mill diameter tolerance+0.0000 to -0.0030 in

Minimum helix angle30

Number of flutes4

Overall length in4

PitchNormal

Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material

Reach length in1-1/2

Shank diameter in1

Shank typeStraight-Cylindrical

Single or double endSingle

Variable helixNo

Variable indexNo
