3/8" 4-Flute Solid Carbide Square End Mill, TiN - RobbJack ST-430-12-T

RobbJack

3/8" 4-Flute Solid Carbide Square End Mill, TiN - RobbJack ST-430-12-T

MFR# ST-430-12-TSeries ST-430

$97.51List $106.14 Save 8%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter3/8
Flutes4
MaterialSolid Carbide
CoatingTiN

Description

The RobbJack ST-430-12-T is a 3/8 4-flute Solid Carbide square end mill. 7/8 length of cut, 2-1/2 overall length. Series ST-430.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishTiN
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Helix angle30
Length of cut in7/8
Length typeRegular
Mill diameter in3/8
Mill diameter tolerance+0.001/-0.000 in
Number of flutes4
Overall length in2-1/2
Overall length tolerance+0.060/-0.060 in
Shank diameter in3/8
Shank diameter tolerance-0.0001/-0.0002 in
Variable helixNo
Variable indexNo
