Seco
Indexable Drilling - Seco 03080721
MFR# 03080721Series PerfoMAX
$738.38List $872.40
Save 15%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Seco 03080721 indexable drilling. Series PerfoMAX.
Specifications
Body length76.74
Collar diameter (mm)35.00
Compatible drill styleSD522
Coolant throughYes
Cutting directionRight Hand
Drill depth by diameter ratio2xD
Flute length (mm)51.74
Insert compatibilitySPGX0703..
Maximum drill depth (mm)46.74
Maximum drill depth range (mm)0.00 to 50.00
Maximum drill diameter (mm)24.42
Number of drill inserts2
Shank diameter in1
Shank length2.2500
Shank typeStraight-Cylindrical
Tool materialSteel
