1/2" 4-Flute Solid Carbide Ball End Mill - SGS 31440

SGS

1/2" 4-Flute Solid Carbide Ball End Mill - SGS 31440

MFR# 31440Series 14B

$100.11List $128.39 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2
Flutes4
MaterialSolid Carbide
CoatingUncoated

Description

The SGS 31440 is a 1/2 4-flute Solid Carbide (Micrograin) ball end mill. 5/8 length of cut, 3 overall length. Series 14B.

Specifications

ChipbreakerNo
Coating finishUncoated
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle30
Length of cut in5/8
Length typeStub
Material gradeMicrograin
Mill diameter in1/2
Mill diameter tolerance+0.000 to -0.002 in
Number of flutes4
Overall length in3
Shank diameter in1/2
Shank diameter tolerance+0.00000 to -0.00043 in
Single or double endDouble
Variable helixNo
Variable indexNo
