3/8" 6-Flute Solid Carbide Square End Mill, TiN - SGS 35101

SGS

3/8" 6-Flute Solid Carbide Square End Mill, TiN - SGS 35101

MFR# 35101Series 51

$66.96List $85.88 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter3/8
Flutes6
MaterialSolid Carbide
CoatingTiN

Description

The SGS 35101 is a 3/8 6-flute Solid Carbide (Micrograin) square end mill. 1 length of cut, 2-1/2 overall length. Series 51.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishTiN
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle41
Length of cut in1
Length of cut range1.0000 - 1.2500
Length typeRegular
Material gradeMicrograin
Mill diameter in3/8
Mill diameter tolerance+0.000/-0.002 in
Number of flutes6
Overall length in2-1/2
Shank diameter in3/8
Shank diameter tolerance+0.00000/-0.00035 in
Shank typeStraight-Cylindrical
Variable helixNo
Variable indexYes
