3/8" 6-Flute Solid Carbide Square End Mill, TiN - SGS 35107

MFR# 35107Series 51L

$102.03List $130.85 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/8

Flutes6

MaterialSolid Carbide

CoatingTiN

Description

The SGS 35107 is a 3/8 6-flute Solid Carbide (Micrograin) square end mill with a Titanium Nitride finish for longer tool life. 1/2 length of cut, 4 overall length. Series 51L.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishTiN

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachYes

Flute directionRight Hand

Flute typeSpiral

Helix angle41

Length of cut in1/2

Length of cut range0.5000 - 0.6000

Length typeLong

Material gradeMicrograin

Mill diameter in3/8

Mill diameter tolerance+0.000/-0.002 in

Number of flutes6

Overall length in4

Reach length in2-1/8

Shank diameter in3/8

Shank diameter tolerance+0.00000/-0.00035 in

Shank typeStraight-Cylindrical

Variable helixNo

Variable indexYes
