SGS

1/2" 6-Flute Solid Carbide Square End Mill, TiN - SGS 35108

MFR# 35108Series 51L

$137.24List $176.02 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/2

Flutes6

MaterialSolid Carbide

CoatingTiN

Description

The SGS 35108 is a 1/2 6-flute Solid Carbide (Micrograin) square end mill with a Titanium Nitride finish for longer tool life. 5/8 length of cut, 4 overall length. Series 51L.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishTiN

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachYes

Flute directionRight Hand

Flute typeSpiral

Helix angle41

Length of cut in5/8

Length of cut range0.6000 - 0.7000

Length typeLong

Material gradeMicrograin

Mill diameter in1/2

Mill diameter tolerance+0.000/-0.002 in

Number of flutes6

Overall length in4

Reach length in2-1/4

Shank diameter in1/2

Shank diameter tolerance+0.00000/-0.00043 in

Shank typeStraight-Cylindrical

Variable helixNo

Variable indexYes

Can't find your exact tool?Send us a part number — we'll cross-reference it. Dull tools?Regrinding extends tool life and saves cost.

Alternate & equivalent tools

Matched on diameter, flute count, and material. Need a specific brand or coating? Cross-reference this tool.
