SGS
1" 3-Flute Solid Carbide Square End Mill, TiB2 - SGS 34754
MFR# 34754Series 43
$658.89List $830.36
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter1
Flutes3
MaterialSolid Carbide
CoatingTiB2
Description
The SGS 34754 is a 1 3-flute Solid Carbide square end mill. Suited for non-ferrous metal. 3-1/4 length of cut, 6 overall length. Series 43.
Specifications
CentercuttingNo
ChipbreakerNo
Coating finishTiB2
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle38
Length of cut in3-1/4
Length of cut range2.0000+
Length typeRegular
Mill diameter in1
Mill diameter tolerance+0.00000/-0.00051 in
Number of flutes3
Overall length in6
Primary workpiece materialNon-Ferrous Metal
Shank diameter in1
Shank diameter tolerance+0.00000/-0.00051 in
Shank typeStraight-Cylindrical
Variable helixNo
Variable indexNo
