Supermill

1/2" 6-Flute Solid Carbide Square End Mill, AlCrN - Supermill 5252290

MFR# 5252290Series SM6F

$68.76List $88.19 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/2

Flutes6

MaterialSolid Carbide

CoatingAlCrN

Description

The Supermill 5252290 is a 1/2 6-flute Solid Carbide (Micrograin) square end mill with a AlCrN finish for longer tool life. Suited for steel, high-temp alloy, cast iron. 1-1/4 length of cut, 3 overall length. Series SM6F.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishAlCrN

Coating finish familyAlCrN

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix angle45

Length of cut in1-1/4

Length of cut range1.2500 - 1.5000

Material gradeMicrograin

Mill diameter in1/2

Number of flutes6

Overall length in3

Primary workpiece materialSteel; High-Temp Alloy; Cast Iron

Shank diameter in1/2

Single or double endSingle

System of measurementFractional Inch

Variable helixNo

Variable indexYes
